- Injection moulded White Polycarbonate body construction
- Acrylic lit panel
- Supplied complete with arrow-down legend as shown
- Lithium Iron Phosphate (LiFePO4) battery cells (not suitable for use below 0oC)
- 3 hours operation on battery power after mains power failure
- Can be installed as maintained or non-maintained. Details in instructions.
- 30m maximum viewing distance
- Self-test version, compliant with BS5266 available.
- Corridors
- Exits
- Escape routes
-Self testing Version is available
-LEGENDS Alternative legends available
Technical datas:
| Model | YG-EB8C-1AS(standard) | YG-EB8C-1AT(self-test) |
| Input Voltage | 220-240V AC | 220-240V AC |
| Power Consumption (W): | 2.5W | 2.5W |
| LED | LED 2835 | LED 2835 |
| Efficiency: | 29LM(Maintain） 29LM(Emergency) | 29LM(Maintain） 29LM(Emergency) |
| CCT L100 (K): | 6500K | 6500K |
| Power factor(PF) | >0.3 | >0.3 |
| Battery | LiFePO4 3.2V 600mAh | LiFePO4 3.2V 600mAh |
| Lifetime | 50000hrs(L70B50) | 50000hrs(L70B50) |
| Size (mm): | 315X40X220mm | 315X40X220mm |
Light Distribution Curve:
